Description

NSN 6110007647621

PART NO. 13219E0883

Voltage Regulator for 3kw, 5kw, and 10kw generator sets

OVERALL LENGTH             10.250 INCHES NOMINAL

OVERALL HEIGHT              3.000 INCHES NOMINAL

OVERALL WIDTH               4.810 INCHES NOMINAL

CIRCUIT TYPE     PARALLEL

REGULATION METHOD  ELECTRONIC

ELECTRONIC DEVICE TYPE             SOLID STATE

COMPENSATION PROVIDED        INDIVIDUAL DROOP

EFFECTIVE CURRENT       1.0 MILLIAMPERES MINIMUM AND 2.0 AMPERES MAXIMUM

REGULATION PERCENT  0.50

RECOVERY TIME                2.00 SECONDS

INPUT CURRENT TYPE     AC

INPUT VOLTAGE RATING IN VOLTS           150.0 NOMINAL

INPUT FREQUENCY RATING IN HERTZ      60.0 NOMINAL

INPUT PHASE     SINGLE

OUTPUT CURRENT TYPE AC AND DC

OUTPUT VOLTAGE RATING IN VOLTS       100.0 MINIMUM AND 150.0 MAXIMUM

OUTPUT CURRENT RATING          2.0 AMPERES NOMINAL
