Isuzu Diesel Engine C240 PW-28
$2,495.00- Engine model: C240
- Characteristics: 4 cycle, water cooled
- Valvetrain configuration: Overhead valve
- Type of aspiration: Naturally aspirated
- Type of injection: Indirect
- Number of cylinders: 4
- Bore x stroke: 3.39 x 4.02 in
- Displacement: 144 cu
- Compression ratio: 20: 1
- Length: 31.5″
- Width: 21.1″
- Height: 27.3″
- Dry Weight: 491 lbs
- Intermittent: 56 HP @3000 RPM
- Continuous: 49 HP @3000 RPM
- Maximum torque: 108 lb-ft @2000 RPM
-
Onan Diesel Engine [From 803A Generator]
$3,800.00– Onan engine from an 803A generator
– 4 Cylinder
– LPW4 (Lister Petter)
– UPC: 40000080449
-
Teledyne Gasoline Engine
Unused – $ 400.00
Used – $ 195.00
Call for availability on each condition.
SPECS:
a. General.
Engine Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 41084-2, -3 and -4
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 4 cycle gasoline powered
Number of cylinders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 4 (horizontally apposed)
Horse power rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 20 at 3600 r.p.m.
Fuel pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Diaphragm 3.0-4.5 psi outlet pressure
Air cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Dry models 4A084-2, -3 and -4
Spark plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. Shielded
Gap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-.033 in. (.071-.083 cm)
Magneto contact
Gap, Fairbanks Morse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..015-.019 in. (.030-.48 cm)
Gap, Slick Aircraft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .008-.012 in. (.020-.030 cm)
Valve tappet clearance cold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..007-.009 in. (.017-.027 cm)
(Intake and exhaust)
Governor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Centrifugal
Oil capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 quarts (4 1/2 gts. with oil filter change)
Alternator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 volts alternating current (ac)
Starter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 volts direct current (dc)
Regulator-Rectifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 28.5 ± .5 volts at 1.5 amps
Firing order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..1-4-2-3
b. Dimensions and Weight Models 4A084, -3 and -4.
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 20 in. (50.8 cm)
Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28.50 in. (72.4 cm)
Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 22.10 in. (56.13 cm)
